| Product Name: | TMDR-240-063 | ||
| Motor parameters | Symbol | Organization | Numerical value |
| Resistance @ 25℃ P-P | R | OHMS | 5.5 |
| Peak current | Ip | Arms | 4.9 |
| Continuous current | Ic | Arms | 19.7 |
| Torque constant | Kf | N-M/Arms | 4.06 |
| Reverse electromotive force | Kb | Vpk/krpm | 347.4 |
| Inductance P-P | L | mH | 8.7 |
| Peak torque | Tp | N-M | 79.7 |
| Continuous torque | Tc | N-M | 19.8 |
| Rated rotational speed | Sp | RPM | 350 |
| Motor constant | Ka | N-M/ w | 1.41 |
| Time constant | Te | ms | 1.6 |
| Peak power | Pp | W | 3195.3 |
| Continuous power | Pc | W | 199.8 |
| Winding temperature | Tmax | C | 120 |
| Rotational inertia | /c | Kg-m2 | 5.8*10-2 |
| Coil weight | WTc | kg | 3.3 |
| Magnet weight | WTf | kg | 6.85 |
Linear motors, voice coil motors & system integration
首页 Torque motor
TMDR-240-063
The coreless AC brushless linear motors (linear motors, linear motors) we provide are applied in servo systems. We offer standard magnetic rails and can be made into platform systems, multi-axis systems, and can also be customized according to customer requirements.
